Electric bike Cube Reaction Hybrid Race 800 vulcan´n´orange 2026

Electric bike Cube Reaction Hybrid Race 800 vulcan´n´orange 2026

(0 review)
About productSpecificationsVideoTechnologiesSize chart

About product

Cube Reaction Hybrid Race 800 vulcan´n´orange

With its rugged go-anywhere capability and 800Wh battery, there's not much that can hold the Reaction Hybrid Race back. It's even PowerMore-ready, so an optional extra 250Wh battery can be added for even more range. The Smart System-equipped Bosch CX drive (100 Nm) has the power to make any route easier, and Sram Transmission 90 12-speed gears put the right ratio literally at your fingertips. Wide, grippy Schwalbe 2.6in tyres are paired with an air-sprung RockShox Recon Silver fork for the best blend of comfort and control. Strong 4-piston hydraulic disc brakes ensure safe and predictable stopping in any conditions. And there's a dropper post, too, so the path less travelled is always within reach.

 Bike in 360° view

Highlights:

  • Elegant aluminum frame with internally routed cables, UDH derailleur hanger, designed for a maximum system weight of 150 kg

  • Motor Bosch Performance Line CX Gen.5 Smart System s 100 Nm

  • Bosch PowerTube 800 Wh battery for long range

  • Bosch Purion 200 display for clear and intuitive e-bike system control

  • RockShox Recon Silver RL Air suspension fork with 120 mm travel (27.5: 100mm)

  • SRAM Eagle 90 Transmission 1x12-speed drivetrain

  • Magura Louise hydraulic 4-piston disc brakes with 203 mm rotors

  • High-quality and robust ACID PRO 30 tubeless-ready wheelset

The Reaction Hybrid's neat and tidy design is no accident. With the 800Wh PowerTube battery neatly concealed and the Bosch CX drive housed securely, its svelte lines disguise lots of clever features. It's PowerMore-ready, making it easy to add up to 250Wh of extra battery capacity. The integrated seat clamp and cable routing complement the clean aesthetic. There's a pre-installed chain guide, and it's ready to accept ACID mudguards and a luggage carrier... plus, with X-Connect, adding a compatible ACID front light is as simple as plugging it into the headset. And, with Size Split, it's easy to find the perfect fit for every rider. Cube has thought of everything, so you can just ride.

Manufacturer item no.: 103300

EAN: 4054571492562

Model year: 2026

Specifications

FrameAluminium Superlite, Gravity Casting Technology, Agile Ride Geometry, Boost148, Fully Integrated Battery, Advanced Internal Cable Routing, 1.5 Headtube, Kickstand/Fender/Carrier Mounting Points
Frame materialaluminium
Wheel sizeClassic: Size Split: 27.5: S // 29: M L XL XXL
Speeds1 x 12
ForkRockShox Recon Silver RL Air, Tapered, 15x110mm, 120mm (27.5: 100mm)
Rear Shock-
Travel120 mm
BrakesMagura Louise, Front 4-Piston/Rear 4-Piston, Hydr. Disc Brake (203)
Brake discs203/203 mm
HeadsetACROS AZF-1034, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), X-Connect Interface
StemCUBE Performance Stem E-MTB 35, FPI-Link
HandlebarCUBE Rise Trail Bar 35
GripACID Hybrid Perform
SaddleACID Sequence 160
SeatpostCUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm
CranksetACID MTB Hybrid Pro, 38T
Rear derailleurSram Eagle 90 Transmission, 12-Speed
Gear shiftersSram Eagle 90 Transmission
Chain guideReverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate
CassetteSram XS-1270, 10-52T
ChainSram GX Eagle™ Transmission
Front tyreSchwalbe Smart Sam, Active, 2.6
Rear tyreSchwalbe Smart Sam, Active, 2.6
WheelsetACID PRO 30, 32/32 Spokes, 15x110mm/12x148mm, Tubeless Ready
DisplayBosch Purion 200 with Integrated Display
BatteryBosch PowerTube 800
ChargerBosch 4A
MotorBosch Drive Unit Performance Line CX Gen.5 max. 100Nm (BDU38)
Bearing dimension-
Maximum total weight allowed160 kg (tbody weight + bike +
equipment)
WeightStarts24,7 kg

Video

From 00:22:21 to 00:24:12 Reaction Hybrid




Technologies

Fully integrated battery

The Fully Integrated Battery system hides the power of the Bosch battery inside the bike’s town tube. The battery is protected by a splash- and dust-proof cover and can be locked to prevent theft. This results in an elegantly designed frame that combines aesthetic appeal with practicality.

Advanced internal cable routing

Gear and brake cables run entirely through the frame—without any additional holes near the headset. Bikes with cable routing through the headset have a clean, elegant look with no unnecessary visual distractions.

Modular Battery System

The battery is the heart of the e-bike. The Modular Battery System makes it easy to use—you can charge the battery on the bike or remove it. The frame also has enough space for higher-capacity batteries, ensuring you always have plenty of range.

Semi-integrated seatpost clamp

The discreet Semi Integrated Seatpost Clamp blends seamlessly with the frame’s design, providing a clean look and reducing the chance of snagging the bike when carrying it.

Boost148

A wider hub means a stiffer and stronger wheel, resulting in better handling. The Boost148 standard allows for greater flange spacing, improving wheel performance without affecting shifting or drivetrain efficiency.


Universal Derailleur Hanger (UDH)

The Universal Derailleur Hanger provides a standardized solution compatible with all drivetrains. It reduces the risk of chain jams, improves shifting performance, and is widely available as a replacement part.

Flat Mount kickstand

The Flat Mount kickstand allows you to park your bike anywhere, providing a secure and stable stand on flat surfaces.

Efficient Trail Control

The Efficient Trail Control system ensures sensitive suspension response on rough terrain while minimizing pedal-induced bobbing. This means full use of the travel and more fun on the trail.

Agile Trail Geometry

Agile Trail geometry is designed for riders who enjoy pushing their limits. A lower frame height and more room for movement provide freetom on the trails and reward bolder line choices.

Size chart

Choosing the correct frame is key to a comfortable and safe ride. Based on your height and inseam length, our frame size calculator helps you find the ideal size for optimal comfort, control, and riding efficiency.

  • Brand
Add to cart
Price
3,699.90 € 3,699.90 € (Tax included)

Check out our dealer network  Where to buy
Contact Us
O izdelkuSpecifikacijeSlike in videoTehnologijaTabela velikosti

O izdelku

Cube Reaction Hybrid Race 800 vulcan´n´orange

Z robustno zasnovo za vse terene in zmogljivo 800 Wh baterijo je Reaction Hybrid Race pripravljen na praktično vse izzive. Poleg tega je PowerMore-ready, kar pomeni, da mu je mogoče dodati dodatno 250 Wh baterijo za še več dosega. Bosch CX pogonski sklop s Smart Systemom in kar 100 Nm navora z lahkoto premaga vsak vzpon, medtem ko 12-stopenjski menjalnik Sram Transmission 90 omogoča natančno in hitro prestavljanje v vseh razmerah. Široke in oprijemljive pnevmatike Schwalbe širine 2,6 palca v kombinaciji z zračno vzmeteno vilico RockShox Recon Silver zagotavljajo idealno ravnovesje med udobjem in nadzorom. Močne 4-batne hidravlične kolutne zavore poskrbijo za varno in zanesljivo zaviranje ne glede na pogoje. Za piko na i je tu še potopna sedežna opora, ki omogoča samozavestno vožnjo tudi tam, kjer se asfalt konča.

 Prikazi kolo v 360° pogledu

Poudarki:

  • Eleganten aluminijast okvir z notranjo napeljavo kablov in nosilcem menjalnika UDH, zasnovan za največjo skupno obremenitev do 150 kg

  • Motor Bosch Performance Line CX Gen.5 Smart System s 100 Nm navora

  • Bosch Powertube 800 Wh baterija za dolg doseg

  • Zaslon Bosch Purion 200 za jasno in intuitivno upravljanje sistema e-kolesa

  • Zračno vzmetena vilica RockShox Recon Silver RL s 120 mm hoda (27,5": 100 mm)

  • Pogonski sklop SRAM Eagle 90 Transmission z 12 prestavami (1x12)

  • Hidravlične 4-batne kolutne zavore Magura Louise s koluti premera 203 mm

  • Kakovosten in robusten obročni set ACID PRO 30, pripravljen za brez-zračnični sistem (tubeless-ready)

Čist in dovršen dizajn modela Reaction Hybrid ni naključje. 800 Wh PowerTube baterija je elegantno skrita v okvir, Bosch CX pogonska enota pa varno nameščena, kar ustvarja vitke linije, za katerimi se skriva obilica pametnih rešitev. Kolo je PowerMore-ready, zato je mogoče preprosto dodati do 250 Wh dodatne baterijske kapacitete. Integrirana objemka sedežne opore in notranja napeljava kablov še dodatno poudarjata minimalističen videz.

Proizvajalčeva šifra: 108400

EAN: 4054571492562

Modelno leto: 2026

Specifikacije

OkvirAluminium Superlite, Gravity Casting Technology, Agile Ride Geometry, Boost148, Fully Integrated Battery, Advanced Internal Cable Routing, 1.5 Headtube, Kickstand/Fender/Carrier Mounting Points
Material okvirjaaluminium
Velikost kolesClassic: Size Split: 27.5: S // 29: M L XL XXL
Število prestav1 x 12
ViliceRockShox Recon Silver RL Air, Tapered, 15x110mm, 120mm (27.5: 100mm)
Zadnji amortizer-
Hod vzmetenja120 mm
ZavoreMagura Louise, Front 4-Piston/Rear 4-Piston, Hydr. Disc Brake (203)
Zavorni rotorji203/203 mm
Krmilni ležajACROS AZF-1034, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), X-Connect Interface
Nosilec krmilaCUBE Performance Stem E-MTB 35, FPI-Link
KrmiloCUBE Rise Trail Bar 35
RočajiACID Hybrid Perform
SedežACID Sequence 160
Sedežna oporaCUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm
GonilkaACID MTB Hybrid Pro, 38T
Zadnji menjalnikSram Eagle 90 Transmission, 12-Speed
Prestavna ročkaSram Eagle 90 Transmission
Zaščita verigeReverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate
VerižnikSram XS-1270, 10-52T
VerigaSram GX Eagle™ Transmission
Sprednji plaščSchwalbe Smart Sam, Active, 2.6
Zadnji plaščSchwalbe Smart Sam, Active, 2.6
Set obročnikovACID PRO 30, 32/32 Spokes, 15x110mm/12x148mm, Tubeless Ready
ZaslonBosch Purion 200 with Integrated Display
BaterijaBosch PowerTube 800
PolnilecBosch 4A
MotorBosch Drive Unit Performance Line CX Gen.5 max. 100Nm (BDU38)
Dimenzija ležajev-
Maksimalna teza150 kg (teža kolesarja + kolo +
oprema)
TežaZačne pri 24,8 kg

Slike in video

Od 00:22:21 do 00:24:12 Reaction Hybrid




Tehnologija

Popolnoma integrirana baterija

Sistem Fully Integrated Battery skrije moč Bosch baterije v notranjost spodnje cevi okvirja. Baterija je zaščitena s pokrovom proti vodi in prahu ter zaklenjena za zaščito pred krajo. Tako nastane elegantno zasnovan okvir, ki združuje lep videz in praktičnost.

Napredna notranja napeljava kablov

Menjalni in zavorni kabli potekajo v celoti skozi okvir – brez dodatnih lukenj pri krmilni cevi. Kolesa z napeljavo skozi krmilni ležaj so vizualno čista, elegantna in brez odvečnih motečih detajlov.

Modularni baterijski sistem

Baterija je srce e-kolesa. Sistem Modular Battery System omogoča preprosto uporabo – baterijo lahko polnite na kolesu ali jo snamete. Okvir ima dovolj prostora tudi za zmogljivejše baterije, zato imate vedno dovolj dosega.

Polintegrirana objemka sedežne opore

Diskretna Semi Integrated Seatpost Clamp se popolnoma zlije z obliko okvirja, kar daje čist videz in manj možnosti, da bi se ob prenašanju kolo kam zataknilo.

Boost148

Širši pesto pomeni togostnejše in trdnejše kolo, kar prinaša boljše vodenje. Standard Boost148 omogoča večjo razdaljo med prirobnicama pesta, kar izboljša zmogljivost koles brez vpliva na prestavljanje in učinkovitost pogona.


Univerzalni nosilec menjalnika (UDH)

Universal Derailleur Hanger prinaša enoten standard, združljiv z vsemi prestavnimi sistemi. Poleg tega zmanjšuje možnost zatikov verige, izboljša prestavljanje in je na voljo povsod kot rezervni del.

Flat Mount stojalo

Za parkiranje kjer koli poskrbi Flat Mount kickstand, ki omogoča varno in stabilno postavitev kolesa na ravnih površinah.

Efficient Trail Control

Sistem Efficient Trail Control zagotavlja občutljivost vzmetenja na neravninah, obenem pa zmanjšuje vpliv poganjanja na nihanje. To pomeni poln izkoristek hoda in več zabave na trailu.

Agile Trail Geometry

Geometrija Agile Trail je zasnovana za kolesarje, ki radi raziskujejo svoje meje. Nižja višina okvirja in več prostora za gibanje omogočata svobodo na trailih in nagrajujeta drznejše linije.

Tabela velikosti

Pravilno izbran okvir je ključ do udobne in varne vožnje. Na podlagi vaše telesne višine in višine razkoraka vam naš kalkulator velikosti okvirja pomaga izbrati idealno velikost za optimalno udobje, nadzor in učinkovitost vožnje.

Frame size calculator

Person figure

Find Your Perfect Bike

Select your height, model, and wheel size to find the recommended frame size.

Your recommended size will appear here.

Attributes

Others
Brand CUBE
